Split System Air Conditioners That Keep One Room CoolWarm

Split system air conditioning installation, service and repairs across Australia. Our licensed technicians fit reverse cycle split systems that heat and cool, sized to the room.

Get a fixed-price quote How it works

At a glance

Split system air conditioning

Best for: One room or open-plan area
Does: Heating and cooling
Common sizes: 2.5 kW to 8 kW
Typical install: Usually one day
We do: Install, service and repair

What is a split system air conditioner?

Two units that move heat, not make it

A split system air conditioner has a wall mounted indoor unit and an outdoor unit, joined by refrigerant pipes. It is called a split because the system is split between the two.

Most are reverse cycle split systems, which run that process in either direction. That is why one unit can cool a room in summer and heat it in winter.

How a split system cools in summerHow a split system heats in winter

Inside

Heat is absorbed

The indoor unit draws warm room air over a cold coil, which soaks up the heat.

In the pipes

Heat is carried out

Refrigerant takes that heat through the wall to the outdoor unit.

Outside

Heat is released

The outdoor unit releases the heat, and cool air keeps flowing into the room.

Outside

Heat is collected

The outdoor unit collects heat from the outside air, even on a cold day.

In the pipes

Heat is carried in

Refrigerant takes that heat through the wall to the indoor unit.

Inside

Warmth is released

The indoor unit blows room air over the warm coil and back into the room.

Benefits

Benefits of a split system air conditioner

Heating and cooling from one unit

Cool the room now, and the same reverse cycle split system will heat it when winter comes.Heat the room now, and the same reverse cycle split system will cool it when summer comes.

Lower upfront cost

With no ducts or ceiling work, a single split system costs far less to install than ducted air conditioning.

Room-by-room control

Each unit has its own remote and thermostat, so you only run the rooms you are using.

Efficient to run

Inverter compressors speed up and slow down to hold the temperature instead of switching on and off.

Quiet indoors

The compressor sits outside, which makes a wall mounted split system a good fit for bedrooms.

Where it suits

Where a split system works best

A split system suits any space you want to heat or cool on its own. These are the places we install them most.

Bedrooms

Quiet, with a sleep mode and a timer, and cheap to run for one room overnight.

Typical size: 2.5 kW

Living areas

A larger unit with wide airflow covers the room everyone uses, kitchen included.

Typical size: 5 to 8 kW

Home offices

Heat or cool the room you work in during the day and leave the rest of the house off.

Typical size: 2.5 kW

Apartments and units

No roof space is needed. The outdoor unit sits on a balcony or a wall bracket.

Typical size: 2.5 to 5 kW

Granny flats and extensions

Add heating and cooling to a new space without touching the system in the main house.

Typical size: 2.5 to 3.5 kW

Not sure it's the one?

Split system vs multi-head vs ducted

The right choice depends on how many rooms you want to heat and cool, and what your home allows. Here is how the three compare.

This page

Split system

One indoor unit, one outdoor unit

Multi-head split

Several indoor units, one outdoor unit

Ducted reverse cycle

One system, vents in every room

Rooms covered

One room or zone

Several rooms

The whole home

Outdoor units

One per indoor unit

One shared unit

One unit

Upfront cost

Lowest

Mid-range

Highest

What your home needs

An outside wall nearby

Pipe runs to each room

Roof or underfloor space for ducts

Best for

Bedrooms, living areas and apartments

Homes with little space outside

Even comfort in every room

Not sure which suits your home? Tell us the rooms you want to heat and cool and we'll recommend one.
